services
Detailed Design
- ASME Section VIII, Division I, II, and III Pressure Vessels
- API 620, 650, 12D, and 12F Storage Tanks and related product Transfer and Handling systems
- API 12J Fired and Electrical Immersion Heated Separators
- API 12K Oilfield Heaters
- Gas Treating Systems and Equipment
- Cryogenic Piping Systems
- Steam, Condensate, and Boiler Feedwater Systems
- Fired Process Equipment, Including API 560 Refinery Heaters
- Stationary High-Pressure Superheated Boilers and Combustion Systems
- Waste Heat Recovery Systems and Equipment
- High-Pressure Industrial Compressed Gas Systems and Equipment
ASME B31.1, B31.3, B31.4, B31.8, B31.9, & B31.12 Code Compliant Piping Systems and Valve Selection/Specifications
Separators and Treaters
Analysis
Metallurgy, Materials & Corrosion
Machine Design
- Pressure Vessel Design, Re-Rating, & Alterations
- ASME Section VIII, Division 2, Part 5 FEA Analysis
- Nozzle Flange Leakage Prediction, External Moments, Loose Bolt, and Flange FEA Stress & Gasket Analysis
- Pressure Vessel & Heat Exchagner Nozzle Loads, Stress, Large Openings, Equipment Supports, and Platforms & Ladders
- Tank & Vessel Heat Loss & Insulation Requirements
- API 579/ASME FFFS-1 Fitness for Service Assessments
- Pipe Stress
- Piping Systems
- Pipe Supports
- Cumulative Damage Assessments
- Crack Prediction Calculations
- Conceptual & Detail Design of Machinery, including Diesel & Gas Turbine Engine Driven Equipment, Electrical Power Generators, Compressors, and Pumps
- Design & Selection of Mechanical Power Transmission Equipment, Reduction Gears, Shafting, and Mechanical Couplings
- Machinery Skids
- Design, Analysis, & Specification of Bolting and Bolted Joints
- Rolling and Journal Bearing Specification & Selection
- Fluid Coupling Specifiation & Selection
- Mechanical Seal Specification & Selection
- Tooling Design & Specification
- Gaseting & Seal Specificfation & Selection
- Selection & Specificaiton of Metallic, Non-Metallic, and Elastomeric Engineering Materials
- Development and/or Evaluation of Welding Procedure Specifications (WPS)
- Corrosion Prediction Models for H2S & CO2 Services
- Specification, Selection, & Recommendations of Thermal Insulation Materials & Systems
- Painting, Coating, and Related Surface Preparation Specifications
- Development of Comprehensive Narrative & Illustrated Technical and Procurment Specifications
- Development of Company Standards, Procedures, and Specifications
- Development of Detailed Comprehensive Equipment Data Sheets
- Client Reivew of Vendor Submittals & Technical Documentation
Technical Documentation
